| Quantity: | |
|---|---|
| Place of Origin:Hebei China (Mainland) | Price:US $25.2 - 37.8 / Set |
| Price Valid Time:15days | HS Code:7314490000 |
| Main Export Market:America, Europe, Australia, Mid-east, Africa, Asia | Means of Transport:by sea |
| Delivery Date:within 15 days | Company Certificate:ISO 9001:2002 |
| Applications:designed to give attractive, long lasting and secure perimeter protection for retail, industrial and commercial properties, schools, and public utilities | |
| Quality Inspection:ISO 9001:2002 | Brand Name:XINHAI |
| Type:Welded Wire Mesh Fence | Material:Low-carbon iron tube, Stainless steel tube ,Aluminum tube |
| Packaging Detail:plastic bags and carton | Delivery Detail:within 18 days |
Material:
Manufactured from hard drawn wire and electro-resistance welded at every intersection.Heavy Low Carbon Wire, Heavy Mild Steel Wire, Stainless Steel Wire.
Coatings and Colors:
Coatings available are galvanized or galvanized and polyester powder coated In standard colors: black and dark green. Other colours are available on request.
Panels | Posts | ||||
Fence | Panel Size | section | O/A Length | Total number of fixings | |
Height (m) | Height/Width (mm) | Inters- 1 Clamp bar | Corners- 2 Clamp bars | ||
2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 |
2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 |
3.0 | 2997 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 |
3.3 | 3302 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 |
3.6 | 3607 x 2515 | 100x60x3mm | 4500 | 13 | |
3.6 | 3607 x 2515 | 100x100x3mm | 4500 | ||
Characters:
1. high security fence, the close mesh means it is virtually impossible to climb.
2. The close mesh also means that the fence is very difficult to cut with anything but power tools.
3. the panels are covered by a continuous heavy weight clamp bar, which offers no place for leverage to prise it off.
4. The system also has no removable fixings meaning that panels cannot be removed by would be intruders.
5. This system has good through visibility and is also aesthetically pleasing.
Applications:
1. Typical applications include industrial units, civic amenities, schools and other such applications where aesthetics are important and security is a concern.
2. Meantime building a welded wire fence is a relatively quick and easy way to keep both the dogs and the kids in the yard.
Specifications
